The full bore brass ball valve 538 BSP with wide flat bearing for shut-off of water, heating, sprinkling, irrigation, air conditioning and compressed air systems.
| Specification | Value |
|---|---|
| DN inches NPS | 3/8'' |
| DN metric | 12/17 |
| Brand | AIRAGA |
| Thread standard | ISO 228-1 |
| Stem sealing material | PTFE Gland packing + EPDM O-ring |
| Type of coating | Nickel-plated |
| Opening device | Handle |
| Application | Industry |
| Shaft/stem matérial | Brass CW614N |
| DN | DN10 - 3/8'' |
| Face to Face (mm) | 51.5 |
| Fluid | Cold water |
| Body material | Brass CW617N |
| Number of ways | 2 |
| Bore | Full |
| Bearing | Large flate |
| Packing gland | Yes |
| PS (bar) | 60 |
| Connections | BSP MM |
| Seats | PTFE |
| Ball material | Chrome-plated brass CW617N |
| TS max (°C) | 120 |
| TS min (°C) | -10 |
| Warranty period | 2 years |
| Handle material | Carbon steel |
| Handle type | Red lever |
If you have any questions about this product, please feel free to contact us.
| Product Name | Product Number | EVAC Number | Price | Add to Cart |
|---|---|---|---|---|
| BSP MM Brass CW617N Full 3/8'' | 538003 | S1010047 |
€4.81
(excl. btw)
|
add to cart |
| BSP MM Brass CW617N Full 1/2'' | 538004 | S1010048 |
€9.30
(excl. btw)
|
add to cart |
| BSP MM Brass CW617N Full 3/4'' | 538005 | S1010049 |
€13.23
(excl. btw)
|
add to cart |
| BSP MM Brass CW617N Full 1'' | 538006 | S1010050 |
€21.61
(excl. btw)
|
add to cart |
